Description

Ethernet Splitter

Ethernet splitter derives Ethernet wire pins 1, 2 and 7 to an external connection, this is a common case for devices using serial connections over Ethernet.

With this device you avoid splitting the Ethernet wire, you can daisy chain the Ethernet wire and disable the connection to the devices, this allow you to verify the connection is working properly using standard Ethernet testers, like is shown in the following figure:

After the line is certified as a standard Ethernet connection, you can derive pins 1, 2 and 7 to your equipment by turning on the switches on the splitter and connect it to your system, like is shown in the following figure:
